UCC28084DRG4
IC REG CTRLR MULT TOPOLOGY 8SOICManufacturer: Texas Instruments
Categories: DC DC Switching Controllers
Quality Control: Learn More
The Texas Instruments UCC28084DRG4 is a highly integrated controller IC designed for high-performance power supply applications. This component features a Half-Bridge, Push-Pull topology, enabling efficient step-up and step-down DC-DC conversion. Key control features include current limiting and frequency control, with a maximum duty cycle of 49% and a switching frequency of 200kHz. It supports a voltage supply range of 4.1V to 15V. The UCC28084DRG4 is packaged in an 8-SOIC (0.154", 3.90mm Width) for surface mount applications and is supplied on tape and reel. This versatile controller is utilized in various industries, including industrial power, consumer electronics, and automotive systems. The device offers two outputs and a single output phase, with the output type configured as a transistor driver.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up/Step-Down |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 200kHz |
| Topology | Half-Bridge, Push-Pull |
| Voltage - Supply (Vcc/Vdd) | 4.1V ~ 15V |
| Supplier Device Package | 8-SOIC |
| Synchronous Rectifier | Yes |
| Control Features | Current Limit, Frequency Control |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 49% |
| Clock Sync | No |
| Number of Outputs | 2 |
