UCC25630-3DDBR
UCC25630-3DDBRManufacturer: Texas Instruments
Categories: DC DC Switching Controllers
Quality Control: Learn More
The Texas Instruments UCC25630-3DDBR is a half-bridge, positive, isolation-capable DC-DC controller IC. This device operates as a transistor driver, offering a maximum duty cycle of 50% and a switching frequency range from 35kHz to 1MHz. It features Hybrid Hysteretic Control (HHC) for robust regulation. Designed for surface mount applications, it is supplied in a 14-SOIC package. The UCC25630-3DDBR supports a voltage supply range of 11.25V to 26V and operates within an ambient temperature range of -40°C to 125°C. This component is suitable for power supply designs in various industries, including industrial automation and consumer electronics.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-SOIC (0.154"", 3.90mm Width), 14 Leads |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | - |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive, Isolation Capable |
| Frequency - Switching | 35kHz ~ 1MHz |
| Topology | Half-Bridge |
| Voltage - Supply (Vcc/Vdd) | 11.25V ~ 26V |
| Supplier Device Package | 14-SOIC |
| Synchronous Rectifier | No |
| Control Features | Hybrid Hysteretic Control (HHC) |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 50% |
| Clock Sync | No |
| Number of Outputs | 1 |
