TL494CNG4
IC REG CTRLR MULT TOPOLOGY 16DIPManufacturer: Texas Instruments
Categories: DC DC Switching Controllers
Quality Control: Learn More
Texas Instruments TL494CNG4 is a versatile pulse width modulation (PWM) controller designed for a wide range of DC-DC converter topologies including Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, and Push-Pull configurations. This device supports step-up, step-down, and step-up/step-down functionality with positive output. Key control features include adjustable dead time and frequency control, with a switching frequency range from 1kHz to 300kHz. The TL494CNG4 offers dual outputs and operates from a 7V to 40V supply voltage. It is packaged in a 16-DIP (0.300", 7.62mm) through-hole mount configuration, suitable for applications in power supplies, industrial automation, and motor control. The operating temperature range is 0°C to 70°C (TA).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-DIP (0.300"", 7.62mm) |
| Output Type | Transistor Driver |
| Mounting Type | Through Hole |
| Function | Step-Up, Step-Down, Step-Up/Step-Down |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 1kHz ~ 300kHz |
| Topology | Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull |
| Voltage - Supply (Vcc/Vdd) | 7V ~ 40V |
| Supplier Device Package | 16-PDIP |
| Synchronous Rectifier | No |
| Control Features | Dead Time Control, Frequency Control |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 45% |
| Clock Sync | No |
| Number of Outputs | 2 |
