LM5116HJD
IC REG CTRLR BUCK 20CDIPManufacturer: Texas Instruments
Categories: DC DC Switching Controllers
Quality Control: Learn More
Buck Regulator Positive Output Step-Down DC-DC Controller IC 20-CDIP
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 20-CDIP (0.300"", 7.62mm) Window |
| Output Type | Transistor Driver |
| Mounting Type | Through Hole |
| Function | Step-Down |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 200kHz, 535kHz |
| Topology | Buck |
| Voltage - Supply (Vcc/Vdd) | 6V ~ 80V |
| Supplier Device Package | 20-CDIP |
| Synchronous Rectifier | Yes |
| Control Features | Enable, Frequency Control, Ramp, Soft Start |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | - |
| Clock Sync | Yes |
| Number of Outputs | 1 |
