LMZ10501SILT
DC DC CONVERTER 0.6-3.6VManufacturer: Texas Instruments
Categories: DC DC Converters
Quality Control: Learn More
Texas Instruments SIMPLE SWITCHER® Nano LMZ10501SILT is a non-isolated Point-of-Load DC-DC converter module. This device provides a single, adjustable output voltage ranging from 0.6V to 3.6V with a maximum output current of 1A. Featuring an input voltage range of 2.7V to 5.5V, it boasts up to 95% efficiency. The LMZ10501SILT incorporates comprehensive protection features including Over-Current Protection (OCP), Over-Temperature Protection (OTP), Short-Circuit Protection (SCP), and Under-Voltage Lockout (UVLO). Control is managed via an active-high Enable pin. This module is designed for surface mount applications, packaged in an 8-LDFN exposed pad format, supplied on tape and reel. Its compact dimensions of 3.0mm x 2.6mm x 1.5mm make it suitable for space-constrained designs. Applications include Information Technology Equipment (ITE) in commercial environments.
Additional Information
Series: SIMPLE SWITCHER® NanoRoHS Status: ROHS3 CompliantManufacturer Lead Time: 6 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | OCP, OTP, SCP, UVLO |
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-LDFN Exposed Pad, Module |
| Size / Dimension | 0.12"" L x 0.10"" W x 0.06"" H (3.0mm x 2.6mm x 1.5mm) |
| Mounting Type | Surface Mount |
| Type | Non-Isolated PoL Module |
| Operating Temperature | -40°C ~ 125°C |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 5.5V |
| Efficiency | 95% |
| Current - Output (Max) | 1A |
| Supplier Device Package | 8-uSIP |
| Voltage - Input (Min) | 2.7V |
| Voltage - Output 1 | 0.6 ~ 3.6V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Control Features | Enable, Active High |
| Number of Outputs | 1 |
