TL331IDBVRE4
IC COMPARATOR 1 DIFF SOT23-5Manufacturer: Texas Instruments
Categories: Comparators
Quality Control: Learn More
Texas Instruments TL331IDBVRE4 is a single-channel, general-purpose comparator featuring an open-collector, rail-to-rail output. This device operates from a wide supply voltage range of 2V to 36V single-ended or ±1V to ±18V dual-ended. It exhibits a low input bias current of 0.25µA at 5V and supports an output current of 20mA. The TL331IDBVRE4 is housed in a SOT-23-5 (SC-74A, SOT-753) surface-mount package, supplied on tape and reel. Typical applications include battery-powered systems, consumer electronics, and industrial control. The operating temperature range is -40°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-74A, SOT-753 |
| Output Type | Open-Collector, Rail-to-Rail |
| Mounting Type | Surface Mount |
| Number of Elements | 1 |
| Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Single/Dual (±) | 2V ~ 36V, ±1V ~ 18V |
| Supplier Device Package | SOT-23-5 |
| Propagation Delay (Max) | - |
| Current - Quiescent (Max) | 700µA |
| Voltage - Input Offset (Max) | 5mV @ 30V |
| Current - Input Bias (Max) | 0.25µA @ 5V |
| Current - Output (Typ) | 20mA |
| CMRR, PSRR (Typ) | - |
| Hysteresis | - |
