LMV761MF
IC COMPARATOR 1 GEN PUR SOT23-6Manufacturer: Texas Instruments
Categories: Comparators
Quality Control: Learn More
Texas Instruments LMV761MF is a single-channel, general-purpose comparator featuring a push-pull output. This SOT-23-6 packaged device operates from a 2.7V to 5V supply range, with typical performance metrics including 100dB CMRR and 110dB PSRR. Input bias current is a maximum of 50pA at 5V, and quiescent current is a maximum of 700µA. Maximum input offset voltage is 0.2mV at 5V. Propagation delay is rated at a maximum of 225ns. The LMV761MF is suitable for applications in the industrial and consumer electronics sectors. It is supplied in tape and reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Last Time BuyPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-23-6 |
| Output Type | Push-Pull |
| Mounting Type | Surface Mount |
| Number of Elements | 1 |
| Type | General Purpose |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply, Single/Dual (±) | 2.7V ~ 5V |
| Supplier Device Package | SOT-23-6 |
| Propagation Delay (Max) | 225ns |
| Current - Quiescent (Max) | 700µA |
| Voltage - Input Offset (Max) | 0.2mV @ 5V |
| Current - Input Bias (Max) | 50pA @ 5V |
| Current - Output (Typ) | - |
| CMRR, PSRR (Typ) | 100dB CMRR, 110dB PSRR |
| Hysteresis | - |
