LMV339MTX
IC COMPARATOR 4 GEN PUR 14TSSOPManufacturer: Texas Instruments
Categories: Comparators
Quality Control: Learn More
Texas Instruments LMV339MTX is a general-purpose comparator featuring four independent elements. This device offers open-collector, CMOS, and TTL compatible outputs, providing flexibility in system design. With a typical input bias current of 0.25µA at 5V and a quiescent current maximum of 300µA, it is suitable for low-power applications. The LMV339MTX operates over a temperature range of -40°C to 85°C and is housed in a 14-TSSOP package. Its 14-TSSOP (0.173", 4.40mm Width) supplier device package facilitates surface mount integration. This component finds application in industrial automation, consumer electronics, and automotive systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Last Time BuyPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-TSSOP (0.173"", 4.40mm Width) |
| Output Type | CMOS, Open-Collector, TTL |
| Mounting Type | Surface Mount |
| Number of Elements | 4 |
| Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Single/Dual (±) | 2.7V ~ 5.5V |
| Supplier Device Package | 14-TSSOP |
| Propagation Delay (Max) | 600ns |
| Current - Quiescent (Max) | 300µA |
| Voltage - Input Offset (Max) | 7mV @ 5V |
| Current - Input Bias (Max) | 0.25µA @ 5V |
| Current - Output (Typ) | 84mA @ 5V |
| CMRR, PSRR (Typ) | - |
| Hysteresis | - |
