TLV320AIC23IPWR
IC AUDIO CODEC 32BIT SER 28TSSOPManufacturer: Texas Instruments
Categories: CODECS
Quality Control: Learn More
Texas Instruments TLV320AIC23IPWR is a stereo audio codec featuring a flexible digital interface supporting I2C and serial communication protocols. This 32-bit audio codec is housed in a 28-TSSOP package, suitable for surface mount applications. It offers 2 ADCs and 2 DACs, with selectable resolutions of 16, 20, 24, and 32 bits. The device boasts a typical dynamic range of 90 dB for both ADCs and DACs, and a signal-to-noise ratio of 90 dB for ADCs and 100 dB for DACs. Operating within an analog supply voltage range of 2.7V to 3.6V and a digital supply voltage range of 1.42V to 3.6V, it is designed for operation between -10°C and 70°C. This component is commonly utilized in consumer electronics, portable audio devices, and automotive infotainment systems. The TLV320AIC23IPWR is supplied on tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Type | Stereo Audio |
| Data Interface | I2C, Serial |
| Operating Temperature | -10°C ~ 70°C |
| Voltage - Supply, Analog | 2.7V ~ 3.6V |
| Voltage - Supply, Digital | 1.42V ~ 3.6V |
| Resolution (Bits) | 16 b, 20 b, 24 b, 32 b |
| Dynamic Range, ADCs / DACs (db) Typ | 90 / 90 |
| Number of ADCs / DACs | 2 / 2 |
| S/N Ratio, ADCs / DACs (db) Typ | 90 / 100 |
| Sigma Delta | Yes |
| Supplier Device Package | 28-TSSOP |
