TLV320AIC13IDBTG4
IC SGL CH CODEC LP LV 30-TSSOPManufacturer: Texas Instruments
Categories: CODECS
Quality Control: Learn More
Texas Instruments TLV320AIC13IDBTG4 is a single-channel, low-power voice-band audio codec featuring a 16-bit resolution for both analog-to-digital and digital-to-analog conversion. This component offers typical dynamic range of 85 dB for ADCs and 92 dB for DACs, with corresponding signal-to-noise ratios of 84 dB and 92 dB. It utilizes a Sigma-Delta architecture for high-fidelity audio processing. The device supports a serial data interface and operates with analog supply voltages between 2.7V and 3.6V, and digital supply voltages from 1.65V to 1.95V. The TLV320AIC13IDBTG4 is housed in a 30-TSSOP package suitable for surface mounting and operates within an ambient temperature range of -40°C to 85°C. This codec is commonly employed in applications such as voice communication systems, portable audio devices, and automotive infotainment.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 30-TFSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Type | Voice-Band |
| Data Interface | Serial |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 2.7V ~ 3.6V |
| Voltage - Supply, Digital | 1.65V ~ 1.95V |
| Resolution (Bits) | 16 b |
| Dynamic Range, ADCs / DACs (db) Typ | 85 / 92 |
| Number of ADCs / DACs | 1 / 1 |
| S/N Ratio, ADCs / DACs (db) Typ | 84 / 92 |
| Sigma Delta | Yes |
| Supplier Device Package | 30-TSSOP |
