CDC582PAH
IC PLL CLOCK DRIVER 52TQFPManufacturer: Texas Instruments
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
The Texas Instruments CDC582PAH is a PLL Clock Driver IC designed for high-performance timing applications. This single-circuit device features a phase-locked loop (PLL) with bypass capability, supporting a maximum output frequency of 100MHz. It accepts LVPECL inputs and provides LVTTL outputs, with configurable division and multiplication ratios from 1:12. The CDC582PAH is housed in a 52-TQFP surface-mount package, measuring 10x10mm, and operates within a 3V to 3.6V supply voltage range. Its operating temperature is specified from 0°C to 70°C. This component is commonly utilized in telecommunications, networking infrastructure, and high-speed computing systems where precise clock generation and distribution are critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 52-TQFP |
| Mounting Type | Surface Mount |
| Output | LVTTL |
| Frequency - Max | 100MHz |
| Type | PLL Clock Driver |
| Input | LVPECL |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 3V ~ 3.6V |
| Ratio - Input:Output | 1:12 |
| Differential - Input:Output | Yes/No |
| Supplier Device Package | 52-TQFP (10x10) |
| PLL | Yes with Bypass |
| Divider/Multiplier | Yes/Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
