CDCVF111FNR
IC CLK BUFFER 1:9 650MHZ 28PLCCManufacturer: Texas Instruments
Categories: Clock Buffers, Drivers
Quality Control: Learn More
Texas Instruments CDCVF111FNR is a high-performance, low-skew clock fanout buffer designed for demanding signal distribution applications. This device features one input and nine LVPECL outputs, capable of operating at frequencies up to 650 MHz with a 1:9 fanout ratio. It supports differential inputs and outputs, ensuring robust signal integrity. The CDCVF111FNR is housed in a 28-PLCC (J-Lead) package suitable for surface mounting and operates across a temperature range of -40°C to 85°C. Its voltage supply range is 3V to 3.6V. This component is commonly utilized in telecommunications, computing, and high-speed data acquisition systems where precise clocking is critical. The Texas Instruments CDCVF111FNR is supplied on tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Last Time BuyPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-LCC (J-Lead) |
| Number of Circuits | 1 |
| Mounting Type | Surface Mount |
| Output | LVPECL |
| Type | Fanout Buffer (Distribution) |
| Input | LVPECL |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3V ~ 3.6V |
| Ratio - Input:Output | 1:9 |
| Differential - Input:Output | Yes/Yes |
| Supplier Device Package | 28-PLCC (11.51x11.51) |
| Frequency - Max | 650 MHz |
