LP3947ISDX-51/NOPB
IC BATT CHG LI-ION 1CELL 14WSONManufacturer: Texas Instruments
Categories: Battery Chargers
Quality Control: Learn More
Texas Instruments LP3947ISDX-51-NOPB is a single-cell lithium-ion battery charger IC. This device, housed in a 14-WSON (4x4) package, supports a maximum supply voltage of 6V and features constant current, programmable charging up to 750mA. The charger includes over-voltage fault protection and interfaces via I2C and USB. Designed for surface mount applications, it operates across a temperature range of -40°C to 85°C. This component is suitable for portable electronics and power management applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-WFDFN Exposed Pad |
| Number of Cells | 1 |
| Mounting Type | Surface Mount |
| Interface | I2C, USB |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Battery Chemistry | Lithium Ion |
| Supplier Device Package | 14-WSON (4x4) |
| Charge Current - Max | 750mA |
| Programmable Features | - |
| Fault Protection | Over Voltage |
| Voltage - Supply (Max) | 6V |
| Battery Pack Voltage | 4.2V |
| Current - Charging | Constant - Programmable |
