TPA6040A4RHBR
IC AMP CLASS AB STER 2.3W 32VQFNManufacturer: Texas Instruments
Categories: Audio Amplifiers
Quality Control: Learn More
Texas Instruments TPA6040A4RHBR is a 2-channel Class AB audio amplifier integrated circuit from the DirectPath™ series. This device delivers 2.3W per channel into a 4-ohm load and 200mW per channel into a 16-ohm load. Featuring differential inputs and a 32-VQFN (5x5) exposed pad package, it is designed for surface mount applications. The TPA6040A4RHBR includes integrated short-circuit and thermal protection, along with a shutdown feature. It operates with a supply voltage range of 4.5V to 5.5V and is rated for an operating temperature of -40°C to 85°C. This component is commonly utilized in consumer electronics and portable audio devices. The device is supplied in a tape and reel package.
Additional Information
Series: DirectPath™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Differential Inputs, Short-Circuit and Thermal Protection, Shutdown |
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-VFQFN Exposed Pad |
| Output Type | 2-Channel (Stereo) with Stereo Headphones |
| Mounting Type | Surface Mount |
| Type | Class AB |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 4.5V ~ 5.5V |
| Max Output Power x Channels @ Load | 2.3W x 2 @ 4Ohm; 200mW x 2 @ 16Ohm |
| Supplier Device Package | 32-VQFN (5x5) |
| Grade | - |
| Qualification | - |
