TAS5701PAPRG4
IC AMP CLASS D STER 20W 64HTQFPManufacturer: Texas Instruments
Categories: Audio Amplifiers
Quality Control: Learn More
Texas Instruments TAS5701PAPRG4 is a 2-channel stereo Class D audio amplifier IC. This device integrates digital audio processing capabilities with a highly efficient Class D output stage, delivering up to 20W per channel into an 8-ohm load. Featuring digital inputs supporting I2S, the TAS5701PAPRG4 facilitates direct digital audio streams. Essential protection features are incorporated, including short-circuit and thermal protection, alongside operational controls like mute and volume. The 64-HTQFP (10x10) package is designed for surface mounting and is supplied on tape and reel. This component is commonly utilized in audio systems for consumer electronics and automotive applications, where high-fidelity audio amplification with power efficiency is critical. The operating temperature range is 0°C to 85°C (TA).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Depop, Digital Inputs, I2S, Mute, PWM, Short-Circuit and Thermal Protection, Shutdown, Volume Contro |
| Packaging | Tape & Reel (TR) |
| Package / Case | 64-PowerTQFP |
| Output Type | 2-Channel (Stereo) |
| Mounting Type | Surface Mount |
| Type | Class D |
| Operating Temperature | 0°C ~ 85°C (TA) |
| Voltage - Supply | 10.8V ~ 13.2V |
| Max Output Power x Channels @ Load | 20W x 2 @ 8Ohm |
| Supplier Device Package | 64-HTQFP (10x10) |
