TAS5424TDKDQ1
IC AMP CLASS D QUAD 116W 44HSSOPManufacturer: Texas Instruments
Categories: Audio Amplifiers
Quality Control: Learn More
The Texas Instruments TAS5424TDKDQ1 is a 4-channel Class D audio amplifier IC. This device is qualified to AEC-Q100 standards and features short-circuit and thermal protection, along with mute and shutdown functions. Designed for automotive applications, it offers depop functionality and differential inputs. The TAS5424TDKDQ1 supports I2C for control and can deliver up to 116W into a 2-ohm load per channel, or 58W into a 4-ohm load per channel. The component is housed in a 44-HSSOP package with an exposed pad for enhanced thermal management and operates within a supply voltage range of 8V to 22V. Its operating temperature range is -40°C to 105°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | Depop, Differential Inputs, I2C, Mute, Short-Circuit and Thermal Protection, Shutdown |
| Packaging | Tube |
| Package / Case | 44-BSSOP (0.433"", 11.00mm Width) Exposed Pad |
| Output Type | 4-Channel (Quad) |
| Mounting Type | Surface Mount |
| Type | Class D |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Voltage - Supply | 8V ~ 22V |
| Max Output Power x Channels @ Load | 116W x 2 @ 2Ohm, 58W x 4 @ 4Ohm |
| Supplier Device Package | 44-HSSOP |
| Grade | Automotive |
| Qualification | AEC-Q100 |
