ADS7808UB/1K
IC ADC 12BIT SAR 20SOICManufacturer: Texas Instruments
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
Texas Instruments ADS7808UB-1K is a 12-bit successive approximation analog-to-digital converter (ADC). This device features a single input channel and supports both SPI and DSP data interfaces. It is designed for applications requiring precise analog signal acquisition with a sampling rate of up to 100kSPS. The ADS7808UB-1K offers a 1:1 sample-and-hold to ADC ratio and accommodates both external and internal voltage references. The component operates from a 5V analog and digital supply voltage and is housed in a 20-SOIC package, suitable for surface mounting. Its operating temperature range is -40°C to 85°C. This ADC finds utility in industrial automation, medical instrumentation, and data acquisition systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-SOIC (0.295"", 7.50mm Width) |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Configuration | S/H-ADC |
| Data Interface | SPI, DSP |
| Reference Type | External, Internal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 5V |
| Sampling Rate (Per Second) | 100k |
| Input Type | Single Ended |
| Number of Inputs | 1 |
| Supplier Device Package | 20-SOIC |
| Architecture | SAR |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
