ADS1256IDBR
IC ADC 24BIT SIGMA-DELTA 28SSOPManufacturer: Texas Instruments
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
The Texas Instruments ADS1256IDBR is a high-precision, 24-bit analog-to-digital converter (ADC). This Sigma-Delta architecture device features a 4- or 8-channel multiplexer (MUX) configurable with a programmable gain amplifier (PGA), enabling versatile input signal conditioning. The ADS1256IDBR offers a sampling rate of up to 30kSPS and communicates via a serial peripheral interface (SPI). It supports both differential and single-ended input types. Operating across an analog supply voltage of 5V and a digital supply range of 1.8V to 3.6V, this component is designed for surface mount applications within a -40°C to 85°C temperature range. Its 28-SSOP package is supplied on tape and reel. This part is commonly utilized in industrial measurement, process control, and high-accuracy instrumentation applications requiring precise analog signal acquisition.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 6 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | PGA |
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-SSOP (0.209"", 5.30mm Width) |
| Mounting Type | Surface Mount |
| Number of Bits | 24 |
| Configuration | MUX-PGA-ADC |
| Data Interface | SPI |
| Reference Type | External |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 1.8V ~ 3.6V |
| Sampling Rate (Per Second) | 30k |
| Input Type | Differential, Single Ended |
| Number of Inputs | 4, 8 |
| Supplier Device Package | 28-SSOP |
| Architecture | Sigma-Delta |
| Ratio - S/H:ADC | - |
| Number of A/D Converters | 1 |
