TS5A3166DBVRG4
IC SW SPST-NOX1 900MOHM SOT23-5Manufacturer: Texas Instruments
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
Texas Instruments TS5A3166DBVRG4 is a single-pole, single-throw (SPST) normally open (NO) analog switch. This device features a low on-resistance of 900mOhm and a -3dB bandwidth of 200MHz. It operates from a single supply voltage ranging from 1.65V to 5.5V, with a maximum leakage current of 20nA. The switch time is 7ns for turn-on and 11.5ns for turn-off. Packaged in a SOT-23-5 (SC-74A, SOT-753), this component is suitable for surface mounting and is supplied on tape and reel. Applications include signal routing and switching in consumer electronics and industrial control systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-74A, SOT-753 |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| On-State Resistance (Max) | 900mOhm |
| -3db Bandwidth | 200MHz |
| Supplier Device Package | SOT-23-5 |
| Voltage - Supply, Single (V+) | 1.65V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - |
| Charge Injection | 1pC |
| Crosstalk | - |
| Switch Circuit | SPST - NO |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | - |
| Switch Time (Ton, Toff) (Max) | 7ns, 11.5ns |
| Channel Capacitance (CS(off), CD(off)) | 19pF, 18pF |
| Current - Leakage (IS(off)) (Max) | 20nA |
| Number of Circuits | 1 |
