TS3A5018DRE4
IC SWITCH SPDT X 4 10OHM 16SOICManufacturer: Texas Instruments
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
Texas Instruments TS3A5018DRE4 is a quad 2:1 analog multiplexer/demultiplexer featuring SPDT switching across four independent circuits. This device offers a low on-resistance of 10 Ohms (max) with channel-to-channel matching of 300 milliohms. With a -3dB bandwidth of 300MHz, it is well-suited for high-frequency signal routing. The device operates from a single supply voltage ranging from 1.65V to 3.6V. Key specifications include a charge injection of 2pC and channel capacitance values of 4.5pF and 9pF (off-state). Crosstalk is rated at -48dB at 10MHz. This component is available in a 16-SOIC package, suitable for surface mounting. Typical applications include signal switching in consumer electronics, industrial automation, and communication systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| On-State Resistance (Max) | 10Ohm |
| -3db Bandwidth | 300MHz |
| Supplier Device Package | 16-SOIC |
| Voltage - Supply, Single (V+) | 1.65V ~ 3.6V |
| Voltage - Supply, Dual (V±) | - |
| Charge Injection | 2pC |
| Crosstalk | -48dB @ 10MHz |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | 300mOhm |
| Switch Time (Ton, Toff) (Max) | 8ns, 6.5ns |
| Channel Capacitance (CS(off), CD(off)) | 4.5pF, 9pF |
| Current - Leakage (IS(off)) (Max) | 100nA |
| Number of Circuits | 4 |
