CD4051BE-NG
IC SWITCH SP8T-O/C 240OHM 16DIPManufacturer: Texas Instruments
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
Texas Instruments CD4051BE-NG is an 8:1 multiplexer/demultiplexer analog switch. This single-circuit device features a low on-resistance of 240 Ohms maximum, with channel-to-channel matching (?Ron) of 5 Ohms. It operates over a supply voltage range of 3V to 20V single supply and maintains performance across an extended temperature range of -55°C to 125°C. The CD4051BE-NG exhibits a -3dB bandwidth of 20MHz and crosstalk of -40dB at 3MHz, with channel capacitance (CS(off), CD(off)) at 5pF and 30pF respectively. Maximum leakage current (IS(off)) is 100nA. The 16-pin PDIP package is suitable for through-hole mounting. This component finds application in industrial automation, consumer electronics, and medical instrumentation.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 16-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 125°C (TA) |
| On-State Resistance (Max) | 240Ohm |
| -3db Bandwidth | 20MHz |
| Supplier Device Package | 16-PDIP |
| Voltage - Supply, Single (V+) | 3V ~ 20V |
| Voltage - Supply, Dual (V±) | - |
| Charge Injection | - |
| Crosstalk | -40dB @ 3MHz |
| Switch Circuit | SP8T - Open/Closed |
| Multiplexer/Demultiplexer Circuit | 8:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | 5Ohm |
| Switch Time (Ton, Toff) (Max) | - |
| Channel Capacitance (CS(off), CD(off)) | 5pF, 30pF |
| Current - Leakage (IS(off)) (Max) | 100nA |
| Number of Circuits | 1 |
