LM62CIM3X
SENSOR ANALOG 0C-90C SOT23-3Manufacturer: Texas Instruments
Categories: Analog and Digital Output
Quality Control: Learn More
The Texas Instruments LM62CIM3X is a local analog temperature sensor designed for surface-mount applications. This device operates within a temperature range of 0°C to 90°C and provides an output resolution of 15.6mV/°C. Its accuracy is rated at ±3°C at 25°C, with a broader ±4°C across the full operating range. The LM62CIM3X is available in a SOT-23-3 package and supports a supply voltage from 2.7V to 10V. Key features include a shutdown mode for power conservation. This component is suitable for use in industrial and consumer electronics applications requiring precise local temperature monitoring.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | Shutdown Mode |
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Output Type | Analog Voltage |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C ~ 90°C |
| Voltage - Supply | 2.7V ~ 10V |
| Sensor Type | Analog, Local |
| Resolution | 15.6mV/°C |
| Supplier Device Package | SOT-23-3 |
| Test Condition | 25°C (0°C ~ 90°C) |
| Accuracy - Highest (Lowest) | ±3°C (±4°C) |
| Sensing Temperature - Local | 0°C ~ 90°C |
| Sensing Temperature - Remote | - |
