MF100CCM
IC FILTER 20KHZ LOW PASS 20SOICManufacturer: Texas Instruments
Categories: Active
Quality Control: Learn More
Texas Instruments MF100CCM is a 2nd order low-pass filter IC featuring a 20kHz cutoff frequency. This component is supplied in a 20-SOIC package, suitable for surface-mount applications. The dual-filter configuration offers flexibility for signal conditioning in various electronic systems. Designed for operation across a 9V to 14V supply voltage range, the MF100CCM is utilized in applications such as audio processing, instrumentation, and industrial control systems requiring precise frequency filtering. The 20-SOIC form factor, with a 7.50mm width, facilitates efficient board space utilization.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 20-SOIC (0.295"", 7.50mm Width) |
| Filter Type | Low Pass |
| Mounting Type | Surface Mount |
| Voltage - Supply | 9V ~ 14V |
| Number of Filters | 2 |
| Filter Order | 2nd |
| Frequency - Cutoff or Center | 20kHz |
| Supplier Device Package | 20-SOIC |
