XX630A1PCM12
ULTRASONIC SENSORS XX, ULTRASONIManufacturer: Telemecanique Sensors
Categories: Proximity Sensors
Quality Control: Learn More
Telemecanique Sensors XX630A1PCM12 is an ultrasonic proximity sensor designed for industrial automation applications. This M30 threaded, cylindrical component offers a sensing distance of 39.37 inches (1000mm) and features an IP67 ingress protection rating for robust operation in demanding environments. The XX630A1PCM12 utilizes a PNP-NC/NO, 4-wire output configuration, enabling versatile integration into control systems. Its plastic body construction and connector termination style contribute to its reliability. This sensor is suitable for use in manufacturing, automotive, and material handling industries where precise distance measurement and object detection are critical. The operating temperature range is 0°C to 60°C.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | Cylinder, Threaded - M30 |
| Output Type | PNP-NC/NO, 4-Wire |
| Sensing Distance | 39.37"" (1000mm) |
| Shielding | Unshielded |
| Operating Temperature | 0°C ~ 60°C |
| Termination Style | Connector |
| Voltage - Supply | 12V ~ 24V |
| Material - Body | Plastic |
| Sensor Type | Ultrasonic |
| Ingress Protection | IP67 |
| Indicator | LED |
| Response Frequency | - |
