SM9333-BBE-S-125-000
SENSOR 0.02PSID 0.12"" 16BIT SOICManufacturer: TE Connectivity Measurement Specialties
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Pressure Sensor -0.02PSI ~ 0.02PSI (-0.12kPa ~ 0.13kPa) Differential Male - 0.12"" (3mm) Tube, Dual 16 b 16-SOIC (0.295"", 7.50mm Width)
Additional Information
Series: SM9333RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Box |
| Package / Case | 16-SOIC (0.295"", 7.50mm Width) |
| Output Type | I2C |
| Mounting Type | Surface Mount |
| Output | 16 b |
| Operating Pressure | -0.02PSI ~ 0.02PSI (-0.12kPa ~ 0.13kPa) |
| Pressure Type | Differential |
| Accuracy | ±3% |
| Operating Temperature | -20°C ~ 85°C |
| Termination Style | PC Pin |
| Voltage - Supply | 3V ~ 5.5V |
| Port Size | Male - 0.12"" (3mm) Tube, Dual |
| Supplier Device Package | 16-SOIC |
| Port Style | Barbed |
| Maximum Pressure | 1.02PSI (7kPa) |
