4515DO-DS3BK030DPL
SENSOR 1.08PSID 0.14"" 14BITManufacturer: TE Connectivity Measurement Specialties
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
TE Connectivity Measurement Specialties 4515DO-DS3BK030DPL is a differential pressure sensor with an operating pressure range of 1.08 PSI (7.48 kPa) and a maximum pressure of 20 PSI (137.9 kPa). This through-hole mount device features a 0.14" (3.56mm) barbed tube port for dual connections and provides a 14-bit I2C output. The sensor offers ±0.25% accuracy and is temperature compensated, operating within a -10°C to 85°C temperature range. It is supplied in an 8-DIP module package and is suitable for board mount applications. This component is utilized in industries such as industrial automation and medical equipment.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 33 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Tray |
| Package / Case | 8-DIP Module |
| Output Type | I2C |
| Mounting Type | Through Hole |
| Output | 14 b |
| Operating Pressure | 1.08PSI (7.48kPa) |
| Pressure Type | Differential |
| Accuracy | ±0.25% |
| Operating Temperature | -10°C ~ 85°C |
| Termination Style | PC Pin |
| Voltage - Supply | 3.3V |
| Port Size | Male - 0.14"" (3.56mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbed |
| Maximum Pressure | 20PSI (137.9kPa) |
