HPP808H031
SENSOR HUMID/TEMP 5V FRQ 3% MODManufacturer: TE Connectivity Measurement Specialties
Categories: Humidity, Moisture Sensors
Quality Control: Learn More
TE Connectivity Measurement Specialties HPP808H031 is a humidity and temperature sensor module operating from a 4.75V to 5.25V supply. This component offers a humidity range of 0 to 100% RH and an operating temperature range of -40°C to 85°C. The output is a frequency signal, with a nominal output of 6.60kHz at 55% RH, and a sensitivity of 12Hz/%RH. The response time is specified at 10 seconds. This sensor is suitable for a variety of applications including environmental monitoring, HVAC systems, and industrial process control. The HPP808H031 is supplied in bulk packaging with the sensor mounted on an exposed board.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Sensor on Exposed Board |
| Output Type | Frequency |
| Sensitivity | 12Hz/%RH |
| Mounting Type | User Defined |
| Output | 6.60kHz @ 55%RH |
| Accuracy | - |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 4.75V ~ 5.25V |
| Sensor Type | Humidity, Temperature |
| Humidity Range | 0 ~ 100% RH |
| Supplier Device Package | - |
| Response Time | 10 s |
