787745-2
CONN RCPT TYPEA STACKED 8POS R/AManufacturer: TE Connectivity AMP Connectors
Categories: USB, DVI, HDMI Connector Assemblies
Quality Control: Learn More
TE Connectivity AMP Connectors offers the 787745-2, a USB-A (USB TYPE-A) stacked receptacle connector. This component features 8 positions with a right-angle, through-hole mounting style, designed for horizontal board placement. The connector supports two stacked ports and is shielded for enhanced signal integrity. Each contact is rated for 1A, with a voltage rating of 30VAC. The 787745-2 boasts a mating cycle rating of 1500 and includes a board lock feature for secure mounting. Its operating temperature range is -55°C to 85°C. This connector is suitable for applications in consumer electronics and industrial automation. It is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Board Lock |
| Packaging | Bulk |
| Voltage - Rated | 30VAC |
| Number of Contacts | 8 |
| Connector Type | USB-A (USB TYPE-A), Stacked |
| Gender | Receptacle |
| Current Rating (Amps) | 1A per Contact |
| Mounting Type | Through Hole, Right Angle |
| Shielding | Shielded |
| Operating Temperature | -55°C ~ 85°C |
| Specifications | - |
| Termination | Solder |
| Ingress Protection | - |
| Mounting Feature | Horizontal |
| Mating Cycles | 1500 |
| Number of Ports | 2 |
