223967-1
CONN HEADER BLADE PWR 3P EDGE MTManufacturer: TE Connectivity AMP Connectors
Categories: Specialized
Quality Control: Learn More
TE Connectivity AMP Connectors UPM Series 223967-1 is a 3-position male blade power header designed for board edge, through-hole, right-angle mounting. This gray connector features a backplane usage with a board guide for enhanced assembly. The contact finish is Gold or Gold-Palladium, providing reliable conductivity. Manufactured by TE Connectivity AMP Connectors, this component is suitable for demanding power applications within the industrial and data communications sectors. Its press-fit termination ensures robust connection.
Additional Information
Series: UPM (Universal Power Modules)RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Board Guide |
| Packaging | Tube |
| Connector Type | Header, Male Blades |
| Contact Finish | Gold or Gold-Palladium |
| Color | Gray |
| Mounting Type | Board Edge, Through Hole, Right Angle |
| Number of Positions | 3 |
| Pitch | - |
| Number of Rows | 1 |
| Number of Positions Loaded | All |
| Termination | Press-Fit |
| Connector Usage | Backplane |
| Connector Style | Blade Power |
| Contact Finish Thickness | - |
| Contact Layout, Typical | 3 Power |
| Number of Columns | - |
