822114-3
CONN SOCKET PQFP 144POS TIN-LEADManufacturer: TE Connectivity AMP Connectors
Categories: IC Sockets
Quality Control: Learn More
TE Connectivity AMP Connectors 822114-3 is a 144-position QFP socket designed for through-hole mounting. This closed-frame socket features a 0.050" (1.27mm) pitch for both mating and post connections. The contact material is Phosphor Bronze with a tin-lead finish, providing a mating contact finish thickness of 200.0µin (5.08µm). The housing is constructed from Liquid Crystal Polymer (LCP), ensuring robust performance in demanding applications. This component is suitable for use in telecommunications and industrial automation systems where reliable interconnectivity for QFP packages is critical. The socket is supplied in tube packaging.
Additional Information
Series: -RoHS Status: Vendor undefinedManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Closed Frame |
| Packaging | Tube |
| Mounting Type | Through Hole |
| Type | QFP |
| Operating Temperature | - |
| Number of Positions or Pins (Grid) | 144 (4 x 36) |
| Termination | Solder |
| Housing Material | Liquid Crystal Polymer (LCP) |
| Pitch - Mating | 0.050"" (1.27mm) |
| Contact Finish - Mating | Tin-Lead |
| Contact Finish Thickness - Mating | 200.0µin (5.08µm) |
| Contact Material - Mating | Phosphor Bronze |
| Pitch - Post | 0.050"" (1.27mm) |
| Contact Finish - Post | Tin-Lead |
| Contact Finish Thickness - Post | 200.0µin (5.08µm) |
| Contact Material - Post | Phosphor Bronze |
