3-87964-4
CONN RCPT 70POS 0.1 GOLD PCB R/AManufacturer: TE Connectivity AMP Connectors
Categories: Headers, Receptacles, Female Sockets
Quality Control: Learn More
70 Position Receptacle Connector 0.100"" (2.54mm) Through Hole, Right Angle Gold
Additional Information
Series: Military, MIL-DTL-55302, AMPMODU Mod IIRoHS Status: Request inventory verificationManufacturer Lead Time: 47 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Connector Type | Receptacle |
| Voltage Rating | - |
| Current Rating (Amps) | - |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 70 |
| Style | Board to Board or Cable |
| Operating Temperature | - |
| Contact Type | Female Socket |
| Fastening Type | Push-Pull |
| Number of Positions Loaded | All |
| Termination | Solder |
| Ingress Protection | - |
| Material Flammability Rating | - |
| Mated Stacking Heights | - |
| Insulation Color | Natural |
| Pitch - Mating | 0.100"" (2.54mm) |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 50.0µin (1.27µm) |
| Contact Finish - Post | Gold |
| Contact Length - Post | 0.145"" (3.68mm) |
| Insulation Height | 0.238"" (6.05mm) |
| Row Spacing - Mating | 0.100"" (2.54mm) |
| Number of Rows | 2 |
Request a Quote
