2-216604-0
CONN RCPT 40POS 0.1 GOLD PCB R/AManufacturer: TE Connectivity AMP Connectors
Categories: Headers, Receptacles, Female Sockets
Quality Control: Learn More
40 Position Receptacle Connector 0.100"" (2.54mm) Through Hole, Right Angle Gold
Additional Information
Series: AMPMODU HV 190RoHS Status: Request inventory verificationManufacturer Lead Time: 55 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Connector Type | Receptacle |
| Voltage Rating | - |
| Current Rating (Amps) | - |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 40 |
| Style | Board to Board |
| Operating Temperature | - |
| Contact Type | Female Socket |
| Fastening Type | Push-Pull |
| Number of Positions Loaded | All |
| Termination | Solder |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - |
| Insulation Color | Green |
| Pitch - Mating | 0.100"" (2.54mm) |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 31.5µin (0.80µm) |
| Contact Finish - Post | Tin |
| Contact Length - Post | 0.126"" (3.20mm) |
| Insulation Height | 0.228"" (5.80mm) |
| Row Spacing - Mating | 0.100"" (2.54mm) |
| Number of Rows | 2 |
Request a Quote
Clients Also Buy
216602-7
CONN RCPT 7POS 0.1 GOLD PCB R/A
216604-3
