281019-2
CONN HEADER VERT 18POS 2.54MMManufacturer: TE Connectivity AMP Connectors
Categories: Headers, Male Pins
Quality Control: Learn More
TE Connectivity AMP Connectors AMPMODU Mod II series header, part number 281019-2, is a shrouded, 18-position, 2-row, right-angle male pin connector. It features a 2.54mm (0.100") pitch and is designed for through-hole mounting. The header utilizes brass contacts with gold plating (15.0µin / 0.38µm) for mating surfaces and tin plating for post surfaces, ensuring reliable connections. With a current rating of 3A and a voltage rating of 40V, this header is suitable for board-to-board or cable applications. The thermoplastic insulation is UL94 V-0 rated, and the operating temperature range is -40°C to 80°C. This component is commonly found in industrial automation, medical equipment, and consumer electronics.
Additional Information
Series: AMPMODU Mod IIRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Connector Type | Header |
| Voltage Rating | 40V |
| Current Rating (Amps) | 3A |
| Mounting Type | Through Hole |
| Number of Positions | 18 |
| Number of Rows | 2 |
| Style | Board to Board or Cable |
| Operating Temperature | -40°C ~ 80°C |
| Contact Type | Male Pin |
| Fastening Type | Detent Lock |
| Number of Positions Loaded | All |
| Termination | Solder |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Contact Material | Brass |
| Insulation Color | Black |
| Pitch - Mating | 0.100"" (2.54mm) |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 15.0µin (0.38µm) |
| Contact Finish - Post | Tin |
| Contact Shape | Square |
| Contact Length - Post | 0.138"" (3.50mm) |
| Insulation Height | 0.496"" (12.60mm) |
| Shrouding | Shrouded - 3 Wall |
| Overall Contact Length | 0.563"" (14.30mm) |
| Insulation Material | Thermoplastic |
| Row Spacing - Mating | 0.100"" (2.54mm) |
| Contact Length - Mating | 0.260"" (6.60mm) |
