7-530666-2
CONN EDGE DUAL FMALE 20POS 0.156Manufacturer: TE Connectivity AMP Connectors
Categories: Edgeboard Connectors
Quality Control: Learn More
20 Position Female Connector Non Specified - Dual Edge Gold 0.156"" (3.96mm) Black
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tray |
| Gender | Female |
| Contact Finish | Gold |
| Color | Black |
| Mounting Type | Through Hole |
| Number of Positions | 20 |
| Pitch | 0.156"" (3.96mm) |
| Operating Temperature | -55°C ~ 105°C |
| Read Out | Dual |
| Contact Type | - |
| Card Type | Non Specified - Dual Edge |
| Card Thickness | 0.055"" ~ 0.070"" (1.40mm ~ 1.78mm) |
| Flange Feature | - |
| Termination | Solder |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Contact Material | Phosphor Bronze |
| Number of Positions/Bay/Row | 10 |
| Number of Rows | 2 |
