7-2340324-1
CONN EDGE DUAL FML 140POS 0.024Manufacturer: TE Connectivity AMP Connectors
Categories: Edgeboard Connectors
Quality Control: Learn More
140 Position Female Connector Non Specified - Dual Edge Gold 0.024"" (0.60mm) Black
Additional Information
Series: Sliver 2.0RoHS Status: RoHS CompliantManufacturer Lead Time: 17 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tray |
| Gender | Female |
| Contact Finish | Gold |
| Color | Black |
| Mounting Type | Board Edge, Straddle Mount |
| Number of Positions | 140 |
| Pitch | 0.024"" (0.60mm) |
| Operating Temperature | -40°C ~ 85°C |
| Read Out | Dual |
| Contact Type | - |
| Card Type | Non Specified - Dual Edge |
| Card Thickness | 0.093"" (2.36mm) |
| Flange Feature | Straddle Mount Opening, Unthreaded, 0.094"" (2.40mm) |
| Termination | Solder |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Contact Material | Copper Alloy |
| Number of Positions/Bay/Row | 28; 14; 28 |
| Number of Rows | 2 |
