2450185-3
RECEPT ASSY, RA, 168 POS, SLIVERManufacturer: TE Connectivity AMP Connectors
Categories: Edgeboard Connectors
Quality Control: Learn More
168 Position Female Connector Non Specified - Dual Edge Gold 0.024"" (0.60mm) Black
Additional Information
Series: Silver 2.0RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: TrayDownload Free CAD Model:
Technical Details:
| Features | Board Guide, Solder Retention |
| Packaging | Tray |
| Gender | Female |
| Contact Finish | Gold |
| Color | Black |
| Mounting Type | Surface Mount, Right Angle |
| Number of Positions | 168 |
| Pitch | 0.024"" (0.60mm) |
| Operating Temperature | - |
| Read Out | Dual |
| Contact Type | - |
| Card Type | Non Specified - Dual Edge |
| Card Thickness | 0.062"" (1.57mm) |
| Flange Feature | - |
| Termination | Solder |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Contact Material | Copper Alloy |
| Number of Positions/Bay/Row | 84 |
| Number of Rows | 2 |
