2-5174341-5
CONN D-TYPE CAP 68POS R/A SLDRManufacturer: TE Connectivity AMP Connectors
Categories: D-Sub Connector Assemblies
Quality Control: Learn More
68 Position D-Type Cap, Male Pins Connector
Additional Information
Series: AMPLIMITE.050 IIRoHS Status: ROHS3 CompliantManufacturer Lead Time: 22 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | Board Lock, Shielded |
| Packaging | Tray |
| Connector Type | Cap, Male Pins |
| Contact Finish | Gold |
| Current Rating (Amps) | 1A |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 68 |
| Number of Rows | 2 |
| Contact Type | Signal |
| Flange Feature | Housing/Shell (M2.5); Latchblocks |
| Termination | Solder |
| Ingress Protection | - |
| Connector Style | D-Type |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Material Flammability Rating | UL94 V-0 |
| Shell Material, Finish | Zinc, Nickel Plated |
| Shell Size, Connector Layout | 0.050 Pitch x 0.100 Row to Row |
| Backset Spacing | 0.149"" (3.80mm) |
