1393481-1
CONN D-SUB RCPT 15POS R/A SLDRManufacturer: TE Connectivity AMP Connectors
Categories: D-Sub Connector Assemblies
Quality Control: Learn More
TE Connectivity AMP Connectors AMPLIMITE HD-20 series 15-position D-Sub receptacle (part number 1393481-1) features female solder termination and a right-angle through-hole mounting style. This connector offers 15 signal contacts with a gold plating for enhanced conductivity and reliability. Designed with a steel, tin-plated shell, it includes mounting brackets and a mating side female screwlock for secure engagement. The connector layout corresponds to shell size 2 (DA, A) and supports a current rating of 2.2A. This component is suitable for applications in industrial automation, telecommunications, and consumer electronics.
Additional Information
Series: AMPLIMITE HD-20RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Mounting Brackets |
| Packaging | Bulk |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Current Rating (Amps) | 2.2A |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 15 |
| Number of Rows | 2 |
| Contact Type | Signal |
| Flange Feature | Mating Side, Female Screwlock (M3) |
| Termination | Solder |
| Ingress Protection | - |
| Connector Style | D-Sub |
| Contact Finish Thickness | - |
| Material Flammability Rating | - |
| Shell Material, Finish | Steel, Tin Plated |
| Shell Size, Connector Layout | 2 (DA, A) |
| Backset Spacing | - |
