1393757-7
CONN MMCX JACK R/A 50 OHM SMDManufacturer: TE Connectivity AMP Connectors
Categories: Coaxial Connector (RF) Assemblies
Quality Control: Learn More
TE Connectivity AMP Connectors MMCX Jack, Right Angle SMD Connector for 50 Ohm impedance applications. This female socket features a snap-on mating mechanism and a solder termination for reliable contact. Operating up to 6 GHz, this coaxial connector is suitable for surface mount applications requiring a compact, right-angle configuration. Its robust design makes it ideal for use in telecommunications, test and measurement equipment, and various RF systems. Supplied in tape and reel packaging for efficient automated assembly.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Connector Type | Jack, Female Socket |
| Contact Termination | Solder |
| Impedance | 50 Ohms |
| Mounting Type | Surface Mount, Right Angle |
| Cable Group | - |
| Fastening Type | Snap-On |
| Ingress Protection | - |
| Connector Style | MMCX |
| Mounting Feature | - |
| Housing Color | - |
| Shield Termination | Solder |
| Center Contact Material | - |
| Frequency - Max | 6 GHz |
| Number of Ports | 1 |
