1051655-1
CONN SMA PLUG STR 50 OHM SOLDERManufacturer: TE Connectivity AMP Connectors
Categories: Coaxial Connector (RF) Assemblies
Quality Control: Learn More
TE Connectivity AMP Connectors SMA Plug, Male Pin, 50 Ohm, Solder termination. This coaxial RF connector, part number 1051655-1, features a threaded fastening type and a free-hanging (in-line) mounting configuration. Designed for RG-188 cable groups, it utilizes a beryllium copper center contact and offers a maximum frequency of 12.4 GHz. The connector's housing is silver in color. This component is suitable for applications requiring robust RF signal transmission in industries such as telecommunications, aerospace, and defense.
Additional Information
Series: -RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Connector Type | Plug, Male Pin |
| Contact Termination | Solder |
| Impedance | 50 Ohms |
| Mounting Type | Free Hanging (In-Line) |
| Cable Group | RG-188 |
| Fastening Type | Threaded |
| Ingress Protection | - |
| Connector Style | SMA |
| Mounting Feature | - |
| Housing Color | Silver |
| Shield Termination | Crimp |
| Center Contact Material | Beryllium Copper |
| Frequency - Max | 12.4 GHz |
| Number of Ports | 1 |
