5786165-1
CONN RCPT FMALE DIN 7POS SOLDERManufacturer: TE Connectivity AMP Connectors
Categories: Circular Connector Assemblies
Quality Control: Learn More
7 Position Circular Connector Receptacle, Female Sockets Solder
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tray |
| Connector Type | Receptacle, Female Sockets |
| Color | - |
| Voltage Rating | 250VAC |
| Current Rating (Amps) | 7.5A |
| Mounting Type | Through Hole, Right Angle |
| Shielding | - |
| Number of Positions | 7 |
| Orientation | Keyed |
| Shell Size - Insert | DIN (270 Degree) |
| Operating Temperature | -55°C ~ 105°C |
| Fastening Type | Push-Pull |
| Termination | Solder |
| Ingress Protection | - |
| Cable Opening | - |
| Material Flammability Rating | UL94 V-0 |
| Mounting Feature | - |
| Shell Size, MIL | - |
| Contact Finish - Mating | Tin |
| Shell Material | Polyamide (PA), Nylon |
| Shell Finish | - |
| Primary Material | Plastic |
