4-2271143-2
CONN RCPT FMALE 5POS GOLD SOLDERManufacturer: TE Connectivity AMP Connectors
Categories: Circular Connector Assemblies
Quality Control: Learn More
TE Connectivity AMP Connectors M12 series, part number 4-2271143-2, is a 5-position female receptacle designed for robust connectivity in demanding environments. This panel mount, through-hole component features a threaded fastening type and a bulkhead mounting feature, facilitating secure integration into equipment. The M12-5 shell size, with a nickel-plated zinc die cast shell and gold-plated copper alloy contacts, ensures excellent durability and signal integrity. It offers an IP68 rating for dust-tight and waterproof operation, making it suitable for industrial automation, sensor and actuator systems, and heavy equipment applications. With a current rating of 4A and a voltage rating of 125VAC/DC, this solder termination connector operates reliably within a temperature range of -40°C to 85°C.
Additional Information
Series: M12RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Connector Type | Receptacle, Female Sockets |
| Color | Silver |
| Voltage Rating | 125VAC/DC |
| Current Rating (Amps) | 4A |
| Mounting Type | Panel Mount, Through Hole |
| Shielding | - |
| Number of Positions | 5 |
| Orientation | A |
| Shell Size - Insert | M12-5 |
| Operating Temperature | -40°C ~ 85°C |
| Fastening Type | Threaded |
| Termination | Solder |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Cable Opening | - |
| Material Flammability Rating | - |
| Mounting Feature | Bulkhead |
| Shell Size, MIL | - |
| Contact Finish - Mating | Gold |
| Shell Material | Zinc Die Cast |
| Shell Finish | Nickel |
| Primary Material | Metal |
