4-2172073-2
CONN RCPT MALE 5POS GOLD SOLDERManufacturer: TE Connectivity AMP Connectors
Categories: Circular Connector Assemblies
Quality Control: Learn More
TE Connectivity AMP Connectors M12 series receptacle, part number 4-2172073-2, features a 5-position male pin configuration with gold-plated contacts for reliable mating. This shielded, panel-mount component utilizes a threaded fastening type and is designed for through-hole termination via solder. With an IP67 rating, it offers dust-tight and waterproof protection, making it suitable for harsh environments. The brass shell, finished in nickel, houses a robust M12-5 insert. This connector has a current rating of 4A and a voltage rating of 125V, operating within a temperature range of -40°C to 85°C. Its bulkhead mounting feature, coupled with board guide and board lock capabilities, ensures secure integration. Applications include industrial automation, sensor and actuator connectivity, and data transmission systems.
Additional Information
Series: M12RoHS Status: Vendor undefinedManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Board Guide, Board Lock |
| Packaging | Bulk |
| Connector Type | Receptacle, Male Pins |
| Color | Silver |
| Voltage Rating | 125V |
| Current Rating (Amps) | 4A |
| Mounting Type | Panel Mount, Through Hole |
| Shielding | Shielded |
| Number of Positions | 5 |
| Orientation | B |
| Shell Size - Insert | M12-5 |
| Operating Temperature | -40°C ~ 85°C |
| Fastening Type | Threaded |
| Termination | Solder |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Cable Opening | - |
| Material Flammability Rating | - |
| Mounting Feature | Bulkhead |
| Shell Size, MIL | - |
| Contact Finish - Mating | Gold |
| Shell Material | Brass |
| Shell Finish | Nickel |
| Primary Material | Metal |
