HAL509 SF-K
MAGNETIC SWITCH SOT-89BManufacturer: TDK-Micronas GmbH
Categories: Switches (Solid State)
Quality Control: Learn More
TDK-Micronas GmbH HAL® 5xy series digital Hall effect switch, part number HAL509-SF-K. This open-drain output device leverages Hall effect technology for reliable magnetic field detection. It features a wide operating voltage range of 3.8V to 24V and a maximum supply current of 5.2mA, with a maximum output current of 20mA. The HAL509-SF-K is designed with temperature compensation for consistent performance across its operating temperature range of -40°C to 140°C (TJ). Packaged in a SOT-89B-1 (TO-243AA, Variant) surface-mount format, this component is supplied on tape and reel. Applications commonly found for this device include automotive systems, industrial automation, and consumer electronics requiring precise position sensing.
Additional Information
Series: HAL® 5xyRoHS Status: ROHS3 CompliantManufacturer Lead Time: 50 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-243AA, Variant |
| Output Type | Open Drain |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 140°C (TJ) |
| Voltage - Supply | 3.8V ~ 24V |
| Technology | Hall Effect |
| Current - Output (Max) | 20mA |
| Current - Supply (Max) | 5.2mA |
| Supplier Device Package | SOT-89B-1 |
