DRF120-24-1
AC/DC DIN RAIL SUPPLY 24V 120WManufacturer: TDK-Lambda
Categories: Industrial, DIN Rail Power Supplies
Quality Control: Learn More
Additional Information
Series: DRF (120-480W)RoHS Status: RoHS CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Power (Watts) | 120W |
| Features | Adjustable Output, Load Sharing, PFC, Remote On/Off, Universal Input |
| Packaging | Bulk |
| Size / Dimension | 4.53"" L x 1.44"" W x 4.86"" H (115.0mm x 36.5mm x 123.4mm) |
| Operating Temperature | -25°C ~ 70°C (With Derating) |
| Applications | Industrial, ITE (Commercial) |
| Input Type | AC or DC |
| Approval Agency | CE |
| Efficiency | 91% |
| Current - Output (Max) | 5A |
| Voltage - Output 1 | 24V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Number of Outputs | 1 |
| Voltage - Isolation | 3 kV |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| AC Voltage - Input | 85 ~ 264 VAC |
| DC Voltage - Input (Min) | 125V |
| DC Voltage - Input (Max) | 370V |
Request a Quote
