IAM-20381
SENSOR ACCELEROMETERManufacturer: TDK InvenSense
Categories: Accelerometers
Quality Control: Learn More
The TDK InvenSense IAM-20381 is a digital accelerometer designed for high-performance applications. This device offers selectable acceleration ranges of ±2g, ±4g, ±8g, and ±16g across its X, Y, and Z axes. It features an I2C and SPI output interface, enabling robust communication. Key functionalities include a selective scale feature, a low-power sleep mode, and an integrated temperature sensor. The IAM-20381 is qualified to AEC-Q100 standards, indicating its suitability for demanding automotive environments. It is supplied in a compact 16-LGA (3x3) package, tape and reel, with a surface mount configuration. Operating within a voltage range of 1.71V to 3.6V, this accelerometer is built for reliability and precision in automotive safety systems and advanced driver-assistance systems (ADAS).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Selective Scale, Sleep Mode, Temperature Sensor |
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-WFLGA Module |
| Output Type | I2C, SPI |
| Mounting Type | Surface Mount |
| Type | Digital |
| Axis | X, Y, Z |
| Acceleration Range | ±2g, 4g, 8g, 16g |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.71V ~ 3.6V |
| Bandwidth | - |
| Supplier Device Package | 16-LGA (3x3) |
| Sensitivity (LSB/g) | 16384 (±2g) ~ 2048 (±16g) |
| Sensitivity (mV/g) | - |
| Grade | Automotive |
| Qualification | AEC-Q100 |
