CXA-0547
INVERTER 12V-INPUT 2100V-OUTPUTManufacturer: TDK Corporation
Categories: Ballasts, Inverters
Quality Control: Learn More
TDK Corporation CXA-0547 is a chassis-mount inverter designed for driving CCFL and UV lamps. This electronic component operates from a nominal input voltage range of 10.8V to 13.2V, delivering a high output voltage of 2100V. Its compact dimensions of 180mm x 37mm x 12mm make it suitable for integration into various systems where space is a consideration. The CXA-0547 is commonly utilized in display backlighting and UV curing applications across industries such as industrial equipment, medical devices, and signage. This component is supplied in tray packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Size / Dimension | 7.09"" L x 1.47"" W x 0.47"" H (180mm x 37mm x 12mm) |
| Mounting Type | Chassis Mount |
| Output | 2100V |
| Voltage - Input | 10.8 ~ 13.2V |
| Type | CCFL and UV Lamps |
