L37S050D15J
CURRENT SENSOR (50A; 15V)Manufacturer: Tamura
Categories: Current Sensors
Quality Control: Learn More
Tamura L37S D15 series Hall Effect current sensor, part number L37S050D15J, offers precise bidirectional current measurement up to 50A. This open-loop module features a single pass-through design for easy integration into power systems. Delivering a ratiometric voltage output with ±1% linearity, it is suitable for applications requiring accurate AC/DC current monitoring. The sensor operates with a supply voltage range of ±12V to ±15V and a maximum supply current of 20mA. Its robust design supports chassis mounting and an operating temperature range of -40°C to 85°C, making it ideal for demanding industrial environments, automotive systems, and power control applications. The typical response time is 3µs.
Additional Information
Series: L37S D15RoHS Status: RoHS CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | Module, Single Pass Through |
| Polarization | Bidirectional |
| Sensitivity | - |
| Mounting Type | Chassis Mount |
| Output | Ratiometric, Voltage |
| Frequency | - |
| Accuracy | - |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | ±12V ~ 15V |
| Response Time | 3µs |
| Sensor Type | Hall Effect, Open Loop |
| Linearity | ±1% |
| For Measuring | AC/DC |
| Current - Supply (Max) | 20mA |
| Current - Sensing | 50A |
| Number of Channels | 1 |
