L16P010D15
SENSOR CURRENT HALL 10A DCManufacturer: Tamura
Categories: Current Sensors
Quality Control: Learn More
Tamura L16P010D15 is a unidirectional, open-loop Hall effect current sensor designed for DC current measurement up to 10A. This single-channel module offers a ratiometric voltage output with an accuracy of ±1% and linearity of ±1%. Featuring a response time of 5µs and a bandwidth up to 35kHz, it is suitable for applications requiring precise and rapid current monitoring. The sensor operates with a supply voltage of ±15V and consumes a maximum of 12mA. Its through-hole mounting type and module package facilitate integration into various electronic systems. This component finds application in power supplies, motor control, and industrial automation.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module |
| Polarization | Unidirectional |
| Sensitivity | - |
| Mounting Type | Through Hole |
| Output | Ratiometric, Voltage |
| Frequency | DC ~ 35kHz |
| Accuracy | ±1% |
| Operating Temperature | -10°C ~ 80°C |
| Voltage - Supply | ±15V |
| Response Time | 5µs |
| Sensor Type | Hall Effect, Open Loop |
| Linearity | ±1% |
| For Measuring | DC |
| Current - Supply (Max) | 12mA |
| Current - Sensing | 10A |
| Supplier Device Package | - |
| Number of Channels | 1 |
