BKP2125HS600-T
FERRITE BEAD 60 OHM 0805 1LNManufacturer: Taiyo Yuden
Categories: Ferrite Beads and Chips
Quality Control: Learn More
The Taiyo Yuden BK series BKP2125HS600-T is a single-line ferrite bead designed for efficient noise suppression in power circuits. This component offers an impedance of 60 Ohms at 100 MHz, making it effective for filtering high-frequency noise. It features a maximum current rating of 3A and a low DC resistance of 25mOhms, ensuring minimal power loss. The 0805 (2012 Metric) package size, with dimensions of 0.079" L x 0.049" W and a maximum height of 0.041", is suitable for surface-mount applications. Operating within a temperature range of -55°C to 85°C, this ferrite bead is utilized in automotive and industrial electronics for EMI reduction. The BKP2125HS600-T is supplied on a Tape & Reel (TR) for automated assembly.
Additional Information
Series: BKRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 0805 (2012 Metric) |
| Filter Type | Power Line |
| Size / Dimension | 0.079"" L x 0.049"" W (2.00mm x 1.25mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 85°C |
| Ratings | - |
| Height (Max) | 0.041"" (1.05mm) |
| Current Rating (Max) | 3A |
| DC Resistance (DCR) (Max) | 25mOhm |
| Number of Lines | 1 |
| Impedance @ Frequency | 60 Ohms @ 100 MHz |
